Product Dimensions 37.5"h x 35.88"w x 29.94"d
Balanced turbulent heat distribution is essential when baking, roasting, and dehydrating food. The American Range convection oven technology features a convection motor and louvered side panels to enhance uniform heat distribution throughout the large oven cavity. The strategic placement of the convection fan ensures consistent heat distribution even when challenged with cooking the largest turkey, ham or roast.Read More
View Options
Sealed burners deliver exceptional performance at every setting and lift off to provide easy clean-up
Variable infinite flame settings for all sealed top burners
Automatic, electronic ignition with fail-safe system ensures re-ignition in the event the flame goes out, even on the lowest burner setting
Continuous commercial-grade cast iron grates allow for easy transfer of pots and pans across the entire cooking surface
Sealed single piece tooled porcelainized cook top can hold more than a gallon of spills
Analog controls provide easy, push and turn operation
Blue light indicates oven functions
Heavy metal die-cast black satin knobs with chrome bezels
Stainless steel Island Back trim included and installed
Multiple functions include: Standard Bake, Convection Bake, Infrared Broil and Fan modes
Convection System optimizes uniform air flow
Two chrome plated heavy duty racks with 4 positions on heavy chrome side supports.
Accommodates full size commercial sheet pan
Front panel switch controls oven lighting for optimal visibility
Oven front construction is a durable, precision-made one piece frame
American Range is pleased to introduce Straight Convection™ Technology. Borrowing from the aerospace industry, we’ve circled our convection bake fan with a powerful ring heater - and straightened out the hot air stream using proprietary air directors. The result is shorter cooking times and more uniform heat transfer for multiple rack cooking - saving time and energy!
The highly efficient design of the Convection Oven uses less gas versus a standard oven.
General Specs | |
Color | Stainless Steel |
Appliance Fit Width (in.) | 36 |
Manufacturer Warranty | 2 Year |
Capacity (cu ft) | 5.3 |
Color Finish Name | Stainless Steel |
ADA Compliant | No |
Range Type | Freestanding |
Number of Elements/Burners | 6 |
Fuel Type | Liquid Propane |
Number of Oven(s) | Single |
Depth (in.) | 29.94 |
Height (in.) | 37.5 |
Width (in.) | 35.88 |
Technical Specifications | |
Oven Dimensions | 32” W x 19” D x 15” H |
Infrared Broiler Element | 17,000 BTU |
Oven Bake Burner Element | 28,000 BTU |
Total BTU's | 114,000 |
Electrical Supply | 120 V; 60 Hz; 15 A |
Shipping Weight | 440 Lbs |
