XO Fabriano Collection 30" Stainless Steel Wall Hood


Model #:

XOS30S

At a Glance

Product Dimensions 44"h x 30"w x 19.69"d

The XOS is a perfect example of Italian design and quality. Beautifully curved front with soft angles make this design a perfect choice without compromising performance.Read More

$699.00

What We Offer

Protect Your Purchase

View Options

None Selected

Get to know this product.

Product Overview

Product Overview

The XOS is a perfect example of Italian design and quality. Beautifully curved front with soft angles make this design a perfect choice without compromising performance. Make Up Air Compliant model numbers end with the designation “MUA”

Features and Benefits:

  • Sones Min to Max are shown below for each model number
  • 3 speed push button controls
  • Two 50 W Halogen Lights – Provide brilliant illumination over the cooking surface
  • High quality Stainless Steel with incomparable handcrafted Italian finish
  • Aluminum Mesh Filters – Trap airborne smoke and grease particles. They can be easily be removed for dishwasher-safe cleaning.
  • Telescoping duct cover fits ceilings up to 9 ft tall
  • Mounting Height from cooking surface 27”-32”

Duct Options and Electrical Requirements:

  • 6 inch duct required
  • Ductless Option for applications where no ducting is available
  • AC 115v—60hz (4amp)

Options:

  • Optional duct cover extension is available for ceilings up to 10′ – Model XOEDCS
  • Optional re-circulation kit available Model XORFK05
Useful Documents
Specifications

General Specs

Width (in.)30
Height (in.)44
Duct Size (in.)6
Depth (in.)19.69
ColorStainless Steel
Color/Finish NameStainless Steel
PositioningStationary
Range Hood TypeWall Mounted
Appliance Fit Width (in.)30
Maximum CFM600
Voltage115

Construction

Chimney:Adjustable

Dimensions

Max Height Above Cooktop:32
Min Height Above Cooktop:27

Display

Controls:Digital

General Features

Filter Type:Aluminum Mesh Filters
Cleanability:Dishwasher Safe

Other

Number of Lights:2
Air Mover(s) Speed:3
Sones (Noise Level) Rating:6.5
